MDSS10/XX-2V(-S)

MDSS10/XX-2V(-S)

SPD for DC supply

PROSURGE® MDSS10/XX-2V(-S)


Technical Features

  • 18mm compact T3 SPD for single phase or two hot lines protection.
  • Max discharge current up to 20kA 8/20μs and open circuit voltage Uoc to 20kV.
  • Pluggable module for easy replacement
  • Reliable thermal disconnector to be fail-safe.
  • Degradation failure indication & optional remote signal contact.
  • Comply with IEC/EN 61643-11, UL 1449 4th, IEEE C62.41, CSA C22.2
